York Flash-Vent Copper Flashing - 40' Roll

SKU FLV03-12
by York
Original price $254.15 - Original price $1,137.23
Original price
$254.15
$254.15 - $1,137.23
Current price $254.15
40.0ft | $6.35 / ft

Ships in 1–2 Weeks

Once an order is placed, no changes, cancellations, or returns are accepted.

Flash-Vent™ Copper is a flexible drainage-plane flashing manufactured from 3-ounce or 5-ounce copper laminated to polymer fabric on one side and drainage fabric on the opposite side.

The integrated drainage fabric provides a continuous pathway for water to drain from the wall cavity while resisting mortar clogging. It eliminates the need for separate mortar-netting material and combines copper flashing with an integrated drainage layer.

Key Features

  • Flexible copper drainage-plane flashing
  • Available in 3-ounce and 5-ounce copper
  • Integrated drainage fabric
  • Provides continuous drainage and weeping
  • Resists clogging from mortar
  • Eliminates the need for separate mortar netting
  • Strong puncture resistance
  • Class A fire-resistant material
  • Mold resistant
  • Manufactured from 90% recycled copper
  • Life-of-the-wall manufacturer warranty
  • Health Product Declaration available

Common Applications

  • Cavity-wall construction
  • Stucco systems
  • Manufactured stone veneer
  • Thin-brick systems
  • Foundation sill flashing
  • Shelf-angle flashing
  • Parapet and coping flashing
  • Head and sill flashing

Compatible Materials and Systems

  • Air barriers
  • Spray polyurethane foam
  • Cavity-wall insulation
  • Construction sealants

Material Construction

  • Copper Options: 3 oz. and 5 oz.
  • Lamination: Polymer fabric laminated to one side
  • Drainage Layer: Drainage fabric laminated to the opposite side
  • Copper Standard: ASTM B370-11

Available Sizes

  • 3 oz. Copper - Gray: 12", 18", 24", and 36" widths × 40' long
  • 5 oz. Copper - Red: 12", 18", 24", and 36" widths × 40' long

Technical Performance

  • Fire Resistance: Class A per ASTM E84
  • Mold Resistance: Passes ASTM D3273

Sustainability

  • Recycled Copper Content: 90%

Warranty

  • Life-of-the-wall manufacturer warranty

Packaging

  • Supplied in 40' rolls

Installation Requirements

  • Install over masonry surfaces that are reasonably smooth and free of loose material.
  • Install with the soft drainage surface facing upward and toward the exterior.
  • Extend the flashing to the leading edge of the cladding.
  • Install horizontal flashing over multiple beads of approved sealant and cover it with a fresh mortar bed.
  • Secure vertical terminations with a termination bar and seal the top edge with an approved sealant.
  • Carry foundation and cavity-wall flashing at least 8" up the backup wall.
  • Extend flashing at least 6" above lintel steel.
  • Extend head and sill flashing at least 6" beyond each side of the opening and turn up the ends to create end dams.
  • Do not overlap adjoining sections.
  • Butt adjoining sections over a 4" splice piece of York 304 SA or a 6" splice piece of Multi-Flash™ 500.
  • Seal the splice with an approved sealant.
  • Fold end dams rather than cutting them.
