Material Construction

• Total Thickness: 20 mil (0.5 mm)
• Facer: 5-mil cross-laminated high-density polyethylene
• Adhesive: 15-mil proprietary modified asphalt
• Membrane Type: Self-adhering composite flashing
• Release Liner: Removable release sheet

Available Sizes and Packaging

• 4" × 75' Rolls - 9 rolls per box
• 6" × 75' Rolls - 6 rolls per box
• 9" × 75' Rolls - 4 rolls per box
• 12" × 75' Rolls - 3 rolls per box

This product is sold in full-box quantities only.

Technical Performance

• Tensile Strength: 6.0 lb per linear inch minimum per ASTM D412
• Elongation at Break: 320% per ASTM D412
• Low-Temperature Pliability: Passes ASTM D146
• Peel Adhesion to Dry Concrete: 5 lb/in per ASTM D903
• Puncture Resistance: 50 lb per ASTM E154
• Permeance: 0.05 perm maximum per ASTM E96B
• Water Absorption: 0.1% by weight maximum per ASTM D570
• Maximum Exposure: 30 days

Installation Requirements

• Install when the air and surface temperatures are above 40°F.
• Surfaces must be clean, dry, and smooth.
• Structural concrete must cure for at least seven days before installation.
• Do not apply over substrates that have absorbed water.
• Prime metal, concrete, and OSB surfaces and allow the primer to dry completely.
• Apply the membrane from the lowest point upward.
• Overlap horizontal edges in shingle fashion.
• Provide a minimum 2" overlap at adjoining sections and seal laps with an approved sealant.
• Roll the membrane firmly with a hard roller to remove wrinkles and air pockets.
• Seal all terminations, details, and penetrations.
• Reinforcing strips and mechanical fastening are recommended at inside corners, outside corners, window frames, and door frames.
• Do not span gaps measuring 1/4" or greater.
• Cover the membrane within 30 days of installation.
