Choosing the Right Wall Tie: PROSOCO Stitch-Tie vs. Stitch-Tie Asymmetric

WHEN TO USE A STANDARD STITCH-TIE VS. AN ASYMMETRIC WALL TIE IN MASONRY RESTORATION

When restoring existing masonry facades, using the correct wall tie is critical for both structural stability and long-term performance. PROSOCO offers two standout solutions for re-anchoring masonry to backup structures: the Stitch-Tie® and the Stitch-Tie Asymmetric. While they look similar at a glance, their differences are essential — and knowing when to use each one can save time, prevent failure, and improve finish quality.

WHAT IS A STITCH-TIE?

The PROSOCO Stitch-Tie is a stainless steel helical pin used to retrofit and re-anchor existing brick, stone, block, or precast facades to their backup structure. These ties are inserted into pilot holes in the veneer and backup wall, providing mechanical connection without adhesives, cure time, or surface disruption.

• Best for general retrofit applications

• Works in all weather

• Ideal for brick, block, stone, and precast

Because it doesn’t add tension between wythes and leaves minimal surface scarring, it’s ideal for historic preservation, repair of failed ties, or restoring facades with no need for tear-down.

WHEN TO USE THE STITCH-TIE ASYMMETRIC

The Stitch-Tie Asymmetric was designed to tackle a common challenge in retrofit anchoring: mismatched substrate hardness.

For example, if you're re-anchoring a soft brick veneer to a hard concrete backup, using a traditional 8mm or 10mm tie can mean drilling large pilot holes into the concrete — which often compromises the softer masonry in the process. The Asymmetric Tie solves this with:

• A small-diameter end (2"–3") for hard backup like concrete or CMU

• A larger-diameter helical end (8mm or 10mm) for softer veneers

This dual-diameter design ensures better grip, less drilling, and optimized performance on both ends — especially in multi-wythe walls or mixed-material retrofits.

COMPARISON AT A GLANCE
